Main processor

Huawei Hi 3520DV300

video compression

H.264(High Profile);

Encode

4*3MP*10fps/4*4MP*8fps

Decode

4*3MP*10fps/4*4MP*8fps

Multi-mode  input

Pure Analog:4*4MP ;
   Mixed:2*4MP(analog) +2*4MP(network);
  Pure Network:4*5MP

Audio compression

G.711A

Intercom

support

Record mode

Manual>alarm>motion detection>timing

Playback Channels

4 (pure local input mode)

Space occupation

1080P*12fps:20~30G/ day*channel
  4MP*8fps:25~35G/ day*channel
  audio:691.2M/ day*channel

Backup mode

Network backup,USB HDD, USB writer,SATA writer

Video input

4 BNC

Video output

1ch VGA,1ch HDMI

Audio input

4ch RCA

Audio output

1ch RCA

Alarm input

NO

Alarm output

NO

Network interface

RJ45 10M/100M Adaptive Ethernet port

PTZ control

RS485; support multiple PTZ protocols

USB

2 USB ports

Hard disk

1SATA(Each maximum support 4T )

Wireless

3G,WIFI(expand via USB)

Power

12V/2A

dimension

255mm(length)* 228mm(width)* 45mm(height)

Main Chipset

NVP2470

Sensor

AR0330

SIGNAL

PAL / NTSC

Lens

MTV 3.6mm HD Fixed Lens

Video Output

1 Channel HD-TVI,, HD-AHD,

Effective Pixels

2048(H)*1536(V)

Min. Illumination

0.01Lux F1.2

Shutter

4/25s~1/45,000s

BLC

optional

Infrared LED

6X6PCS

Infrared Distance

25M

OSD

Supported

 Day/Night

Auto(ICR) / Color / B/W

Transmission Distance

Over 500m via 75-3 coaxial cable

Power Supply

DC 12V/±10% ,2000mA

Working Environment

-20℃   --- 50℃

Dimension (mm)

173(W) x67(H) x54(D)mm

NW

0.8KG
