CNTAHDKIT404
Product name : CNTAHDKIT404
Model No. : 4 CH 1080 AHD DVR KIT (DOME/BULLET)
Products Category: > AHD DVR KIT > 1080P
· Resolution: 1920*1080P
· Certificate: CE/FCC/ROHS/ISO9001
· Weatherproof: IP66
· 4CH AHD 1080P DVR: 1PC
· AHD 1080P camera: 4pcs
· 5A Power Supply: 1pcs
· 20m Cables: 4pcs
· Mouse: 1pcs
· 5 in 1 power cable: 1pcs
· Warranty: 2 Years
Product Description
4CH 1080P DVR 2000TVL 2MP AHD Cameras 20M Weatherproof IP66 Motion detect ahd security surveillance system
Model | |
Main processor | Hi3531 |
Operating system | embedded Linux |
System resources | Simultaneous multi-channel real-time recording, playback, network operation, USB backup |
User interface | support 16-bit true color graphical menu interface and mouse operation |
Preview screen | 1/4 |
Video Standard | PAL/NTSC(1080P) |
Video compression | H.264(High Profile); JPEG snapshot |
Display quality
| VGA,HDMI:HD |
(support 1920*1080, 1280*720,1440*900,1280*1024, 1024*768, | |
Encode capacity | 4*AHD-H(1080P)@12fps/4*AHD-M@25fps |
Decode capacity | 4*AHD-H(1080P)@12fps/4*AHD-M@25fps |
Multi-mode input
| Pure analog: 4* AHD-H(1080P)/4*AHD-M(720P) |
pure network: 4*720P+1*1080P/2*1080P/20*AHD-L | |
analog + network: 2*AHD-M(720Panalog) +2*1080P(network) | |
Motion Detection | Each screen can be set to 192 (16*12) detection areas; multi-level |
Audio compression | G.711A |
Intercom | support |
Record mode | manual>alarm>motion detection>timing |
Playback | 4* AHD-H(1080P)@12fps/4*AHD-M@25fps |
Video Search | Time, calendar, event, channel |
Space occupation | Video:1080P 40G / day* channel; 720P 20G / day * channel; Audio: 691.2M / day * channel |
Video storage | HDD, network |
Backup mode | Network, U-disk, USB burner, SATA burner |
Video input | 4ch BNC |
Video output | 1ch VGA, 1ch HDMI |
Audio input | 4ch RCA |
Audio output | 1ch RCA |
Alarm input | NO |
Alarm output | NO |
Network interface | RJ45 10M/100M |
PTZ control | 1*RS485, Support multiple PTZ protocols |
USB | 2* USB 2.0 |
HDD | 1*SATA port (Max 4TB/per) |
Wireless | 3G, WIFI (extension via USB) |
Power supply | 12V/4A |
Power Consumption | <15W (without hard drive) |
Temperature | 0℃-+55℃ |
Humidity | 10%-90% |
Atmospheric pressure | 86kpa-106kpa |
Model | |
Pick up Element | 1/2.7" OV |
Effective Picture Elements (H×V) | PAL/NTSC : 1920*1080 |
Horizontal Resolution | 1920H |
Scanning System | 2:1 interface |
Synchronous System | Internal, Negative sync |
Auto Electronic Shutter | 1/50(1/60)S-1/100,000S |
Gama Characteristic | 0.45 |
IR Distance | 25Meters (with 6X6PCS Infrared LED) |
IR Status | Under 10Lux by CDS |
IR Power On | CDS AUTO Control |
Video Output | 1Vpp, 75Ω |
Auto Gain Control | Auto |
Power/Current | DC12V/2000mA ±10% |
Lens | MTV 3.6mm HD Fixed Lens |
Dimension (mm) | 69 x 94(H) |
Storage Temperature | -30~+60℃ RH95% MAX |
Operating Temperature | -10~+60℃ RH95% MAX |
NW | 0.5kg |
