CNTAHDKIT-204
Product name : CNTAHDKIT-204
Model No. : 16 CH MOTION DEDECTION (DOME/BULLET)KIT
Products Category: > AHD DVR KIT > 720P
· Resolution: 1280*720P
· Certificate: CE/FCC/ROHS/ISO9001
· Weatherproof: IP66
· 16CH AHD 720P DVR: 1PC
· AHD 720P camera: 16pcs
· 5A Power Supply: 4pcs
· 20m BNC Powerb Cable: 16pcs
· Mouse: 1pcs
· 5 in 1 power cable: 4pcs
· Warranty: 2 Years
Product Description
16CH 1MP 720P 1200TVL DVR 25M AHD bullet Cameras Motion detect Weatherproof IP66 ahd security cameras systems
System | Main processor | Industrial-grade embedded HiSilicon CPU | |||||
Operating system | embedded Linux | ||||||
System resources | Simultaneously multi-channel real-time recording, playback, network operation, USB backup | ||||||
Interface | Operator interface | support 16-bit true color graphical menu interface and mouse operation | |||||
Preview | 1/4/8/16 split screen | ||||||
Video | Codec | H.264(High Profile) | |||||
Monitor quality | VGA;HDMI:HD | ||||||
Playback quality | TVI,CVI,AHD-1080N | ||||||
Encode ability | 16*TVI,CVI,AHD-1080N | ||||||
Decode ability | 4*TVI,CVI,AHD-1080N | ||||||
Multi-mode | analog:16*TVI,CVI,AHD-1080N; | ||||||
hybrid:12*TVI,CVI,AHD-1080N(analog)+4*720P(network) | |||||||
Network only:8*720P; | |||||||
Motion Detection | Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel) | ||||||
Audio compression | G.711A | ||||||
Intercom | support | ||||||
Record & playback | Record mode | manual>alarm>motion detection>timing | |||||
Local Playback | 4ch(local input mode) | ||||||
Search mode | Search by time, calendar, event, channel | ||||||
Storage & backup | Video storage | HDD, network | |||||
Backup mode | Network, USB hard disk, USB burner, SATA burner | ||||||
External Interface | Video input | 16ch BNC | |||||
Video output | 1ch VGA, 1ch HDMI | ||||||
Audio input | 4CH RCA | ||||||
Audio output | 1CH RCA | ||||||
Alarm input | 0( Can be extended to 4ch) | ||||||
Alarm output | 0( Can be extended to 1ch) | ||||||
Network interface | RJ45 10M/100M self-adaption | ||||||
PTZ control | 1*RS485, Support kinds of PTZ protocols | ||||||
USB | 2* USB 2.0 ports | ||||||
HDD | 1*SATA ports (Max 6TB/per) | ||||||
Wireless | 3G, WIFI (extend via USB) | ||||||
General | Power supply | 12V/2A | |||||
Power Consumption | <15W (without HDD) | ||||||
Temperature | 0℃—+55℃ | ||||||
Humidity | 10%—90% | ||||||
Working environment | 86kpa—106kpa | ||||||
Pick up Element | 1/4"OV | ||||||
Effective Picture Elements (H×V) | PAL/NTSC : 1280*720 | ||||||
Horizontal Resolution | 1280H | ||||||
Scanning System | 2:1 interface | ||||||
Synchronous System | Internal, Negative sync | ||||||
Auto Electronic Shutter | 1/50(1/60)S-1/100,000S | ||||||
Gama Characteristic | 0.45 | ||||||
IR Distance | 30Meters (with 8X6PCS Infrared LED) | ||||||
IR Status | Under 10Lux by CDS | ||||||
IR Power On | CDS AUTO Control | ||||||
Video Output | 1Vpp, 75Ω | ||||||
Auto Gain Control | Auto | ||||||
Power/Current | DC12V/2000mA ±10% | ||||||
Lens | MTV 3.6mm HD Fixed Lens | ||||||
Dimension (mm) | 254(W)*68(H)* 58(D) mm | ||||||
Storage Temperature | -30~+60℃ RH95% MAX | ||||||
Operating Temperature | -10~+60℃ RH95% MAX | ||||||
NW | 0.8 KG | ||||||
