CNTAHDKIT-205
Product name : CNTAHDKIT-205
Model No. : 1MP 4 CH AHD DVR KIT (DOOM/BULLET)
Products Category: > AHD DVR KIT > 720P
· Resolution: 1280*720P
· Certificate: CE/FCC/ROHS/ISO9001
· Weatherproof: IP66
· 4CH AHD 720P DVR: 1PC
· AHD 720P camera: 4pcs(DOOM/BULLET )
· 5A Power Supply: 1pcs
· 20M Cable: 4pcs
· Camera: 1/4" CMOS
· 5 in 1 power cable: 1pcs
· Warranty: 2 Years
Product Description
4CH 720P AHD DVR 4pcs 1MP 20M IR range dome AHD Cameras Motion detect IP66 ahd night owl security system
System | Main processor | Industrial-grade embedded HiSilicon CPU |
Operating system | embedded Linux | |
System resources | Simultaneously multi-channel real-time recording, playback, network operation, USB backup | |
Interface | Operator interface | support 16-bit true color graphical menu interface and mouse operation |
Preview | 1/4 split screen | |
Video | Codec | H.264(High Profile) |
Monitor quality | VGA;HDMI:HD | |
Playback quality | AHD-1080N | |
Encode ability | 4*AHD-1080N | |
Decode ability | 4*AHD-1080N | |
Multi-mode | analog:4*AHD-1080N; | |
input | hybrid:2*AHD-M(analog)+2*720P(network) | |
Network only::8*720P;8*1080P; | ||
Motion Detection | Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel) | |
Audio compression | G.711A | |
Intercom | support | |
Record & playback | Record mode | manual>alarm>motion detection>timing |
Local Playback | 4ch(local input mode) | |
Search mode | Search by time, calendar, event, channel | |
Storage & backup | Video storage | HDD, network |
Backup mode | Network, USB hard disk, USB burner, SATA burner | |
External Interface | Video input | 4ch BNC |
Video output | 1ch VGA, 1ch HDMI | |
Audio input | 4CH RCA | |
Audio output | 1CH RCA | |
Alarm input | 0( Can be extended to 4ch) | |
Alarm output | 0( Can be extended to 1ch) | |
Network interface | RJ45 10M/100M self-adaption | |
PTZ control | 1*RS485, Support kinds of PTZ protocols | |
USB | 2* USB 2.0 ports | |
HDD | 1*SATA ports (Max 6TB/per) | |
Wireless | 3G, WIFI (extend via USB) | |
General | Power supply | 12V/2A |
Power Consumption | <15W (without HDD) | |
Temperature | 0℃—+55℃ | |
Humidity | 10%—90% | |
Working environment | 86kpa—106kpa | |
Dimension | 255*50*220mm | |
Weight | 2KG | |
Pick up Element | 1/4"OV |
Effective Picture Elements (H×V) | PAL/NTSC : 1280*720 |
Horizontal Resolution | 1280H |
Scanning System | 2:1 interface |
Synchronous System | Internal, Negative sync |
Auto Electronic Shutter | 1/50(1/60)S-1/100,000S |
Gama Characteristic | 0.45 |
IR Distance | 25Meters (with 6X6PCS Infrared LED) |
IR Status | Under 10Lux by CDS |
IR Power On | CDS AUTO Control |
Video Output | 1Vpp, 75Ω |
Auto Gain Control | Auto |
Power/Current | DC12V/2000mA ±10% |
Lens | MTV 3.6mm HD Fixed Lens |
Dimension (mm) | 69 x 94(H) |
Storage Temperature | -30~+60℃ RH95% MAX |
Operating Temperature | -10~+60℃ RH95% MAX |
NW | 0.5kg |
