CNT-HYB2002
Product name : CNT-HYB2002
Model No. : 3.0mp 2048*1536p Hybrid 2 in 1 AHD TVI
Products Category: > HYBRID CAMERA
· Sensor: CMOS
· Technology: Infrared
· Special Features: Waterproof / Weatherproof
· Resolution: 2048*1536P
· Image Sensor: 1/3" CMOS AR0330
· DSP: NVP2470H
· IR Distance: 30Meters
· Certificate: CE/FCC/ROHS/ISO9001
· Weatherproof: IP66
· Warranty: 2 Years
· Camera type: AHD Analog Camera
· Lens: 3.6mm Board Lens
· 3.0mp 2048*1536p Hybrid 2 in 1 AHD TVI hd home security cameras analog buttle camera
Model | O2IN1300A-MBPE30 |
Main Chipset | NVP2470H |
Sensor | AR0330 |
SIGNAL | PAL / NTSC |
Lens | Board Len 3.6mm (3MP) |
Video Output | 1 Channel AHD TVI |
Effective Pixels | 2048(H)*1536(V) |
Min. Illumination | 0.01Lux F1.2 |
Shutter | 4/25s~1/45,000s |
BLC | optional |
Infrared LED | 8X6PCS |
Infrared Distance | 30M |
OSD | Supported |
Day/Night | Auto(ICR) / Color / B/W |
Transmission Distance | Over 500m via 75-3 coaxial cable |
Power Supply | DC 12V/±10% 2000mA |
Storage Temperature | -30~+60℃ RH95% MAX |
Operating Temperature | -10~+60℃ RH95% MAX |
NW | 0. 8KG |
