CNT-IP3449
Product name : CNT-IP3449
Model No. : 4MP CMOS IP66 40M IR Range 2.8-12mm WDR IP
Products Category: > IP CAMERA(H265+/H265/H264) > H264 IP CAMERA
· Resolution: 4MP
· Image Sensor: OV4689 1/3"
· DSP: S2L-55M
· Certificate: CE/FCC/ROHS/ISO9001
· Weatherproof: IP66
· Lens: 2.8-12mm Manual Zoom
· Shape: BOX
· White light: Support
· IR Distance: 40m
Product Description
4MP CMOS IP66 40M IR Range 2.8-12mm Zoom white light BOX ip camera prices
| Model NO. | OIP40A-MB40 | |
| Image Sensor | OV4689 1/3"CMOS | |
| Main processor | S2L-55M | |
| Resolution | 4MP | |
| Effective Pixels | 2592(H)*1520(V) | |
| TV System | PAL/NTSC | |
| Sync System | External | |
| Usable Illumination | color 0.05lux F1.2; black and white 0 lux F1.2 | |
| Scanning System | Progressive | |
| Video Output | Network | |
| Lens | 2.8-12mm | |
| HD Manual Zoom Lens(2.0MP) | ||
| Infrared LED | 2PCS | |
| Infrared Distance | 40M | |
| IR Status | Under 10 Lux By CDS | |
| IR Power On | CDS Auto Control | |
| Ethernet | RJ-45 (10/100Base-T) | |
| Protocol | Support FTP, E-mail, Browser, CMS Protocol TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,FTP, NTP,PPPOE,SMTP,UPNP | |
| P2P | YES | |
| POE | Optional | |
| Main Stream | 2592×1520@15fps | |
| Sub Stream | 704×576@30fps | |
| 640×360@30fps | ||
| IE Brower | Mozilla Firefox, Internet Explorer 7.x or above | |
| Smart Phone | iPhone, iPad, Android, Android Pad | |
| Day/Night | Color/ B&W (IR-CUT ) | |
| Compression | H.264/MJPEG | |
| Image Config | Saturation/Brightness/Contrast /Sharpness, AUTO E W,White Balance,Horizon Flip,Vertical Flip | |
| Motion Detection | Support | |
| Recording Mode | NVR/CMS/Web | |
| Operation Temperature | -20℃~+55℃ RH95% Max | |
| Storage Temperature | -10℃ ~ +60℃ RH95% Max | |
| Power Source | DC12V±10% | |
