CNT-IP7809
Product name : CNT-IP7809
Model No. : 2MP 1080P H265 POE IP CAMERA
Products Category: > IP CAMERA(H265+/H265/H264) > H265 IP CAMERA
OIP200PWDR-MB40 2MP 1080PH.265/H.264 IR range White Light 40m P2P POE SD Card RIO ONVIF2.4 WDR HLC BOX security camera ip
· Sensor: CMOS
· Technology: NetWork
· Special Features: Waterproof / Weatherproof
· Resolution: 1920*1080P
· Image Sensor: Panasonic 34229
· DSP: HI3516D
· Certificate: CE/FCC/ROHS/ISO9001
· Weatherproof: IP66
· Warranty: 2 Years
· Lens: 6mm 3.0 MP CS lens
· Shape: BOX
· IR Distance and White light: 40m
· Camera type: WDR HLC IP Camera
| Model NO. | OIP200PWDR-MB40 |
| Image Sensor | Panasonic 34229 |
| Main processor | HI3516D |
| Resolution | 2.1MP |
| Effective Pixels | 1920(H)*1080(V) |
| TV System | PAL/NTSC |
| Sync System | External |
| Usable Illumination | color 0.05lux F1.2; black and white 0 lux F1.2 |
| Scanning System | Progressive |
| Video Output | Network |
| Lens | 6mm 3.0 MP CS lens |
| Infrared LED | 2PCS |
| Infrared Distance | 40M |
| IR Status | Under 10 Lux By CDS |
| IR Power On | CDS Auto Control |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | Support FTP, E-mail, Browser, CMS |
| P2P | YES |
| POE | Optional |
| Main Stream | 1920*1080@30fps |
| Sub Stream | 704×576@30fps |
| 640×360@30fps | |
| IE Brower | Mozilla Firefox, Internet Explorer 7.x or above |
| Smart Phone | iPhone, iPad, Android, Android Pad |
| Day/Night | Color/ B&W (IR-CUT ) |
| Compression | H.264/MJPEG/H.265 |
| Image Config | Saturation/Brightness/Contrast /Sharpness, AUTO E W, White Balance, HLC,Horizon Flip,Vertical Flip |
| Motion Detection | Support |
| Recording Mode | NVR/CMS/Web |
| Operation Temperature | -20℃~+55℃ RH95% Max |
| Storage Temperature | -10℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10% |
